SQ7M Industrial Joystick
Category：
SQ7M product features ergonomic, grip type operation multi-axis operation,spring return,Strong handle for use in harsh environments with contactless Halltechnology, high reliability,Long - life electronic part protection class IP67lt is suitable for industrial automation of hoisting machinery at high altitude
多行文本内容元素
富文本内容绑定数据后可解析HTML语言内容
Details
| Data | |
| Model: | SQ7M |
| Adjustable Angle: | ±20° |
| Operating force: | 8N |
| Service life: | <1million |
| Supply voltage | (Vs):5±0.5Vdc |
| Supply current: | <12mA(Per channel) |
| Median voltage: | 2.5V±2%Vs |
| Output linear error: | ±2.5% |
| Maximum overload voltage: | 20Vdc |
| Maximum reverse voltage: | -12Vdc |
| Load resistance: | 10KQ |
| Operating temperature: | -40°C~+70°C |
| Storage temperature: | -40°C～+85°C |
| Protection class: | IP67 |
| EMC: | EN6100-6-4-2007,30MHz-1GHz |
| EN6100-6-2-2019,80MHz-6GHz | |
